QMAN

Paperless Repair Software

QMAN helps all common test systems to repair faster as well as monitor and evaluate the production process

  • Fast fault diagnostics and repair
  • Enables conclusions to be drawn for improving performance and quality
  • Visual inspection stations with checklists
  • Process monitoring with automatic serial fault detection
  • Intelligent repair database
  • Comprehensive statistical reports
  • Drill-down functions

Paperless Repair

The Paperless Repair software QMAN is a powerful quality management system. It helps achieve higher quality assurance, reduce production costs and shorten repair time – regardless of which test system you are using.

Input

QMAN captures test results from equipment like AOI, AXI, SPI, ICT, Boundary Scan, functional and flying probe test, as well as from manual inspection and end-of-line test.

Failure processing

QMAN speeds up repair by displaying the fault location and repair suggestion in our fully integrated layout and schematic viewers.

Analyze

Generates comprehensive drill down reports to analyze and observe the production process. For example KPI reports like FPY and DPMO and WIP.

Failure Import

  • Interface to test and inspection systems.
  • With the additional debug tool new interfaces can be created and customized.

Repair Station

To optimize repair time, paperless repair has an integrated failure catalog, schematics and layout viewer.

Trendalarm

Customized trend alarms can be configured to monitor the production process.

Visual Inspection Station

Each PCB type can get one or more checklists for visual inspections assigned. The checklists are stored one central place in the database.

Functional Test Station

All test systems, which do not have a data log functionality can be connected to QMAN.

Packing Station

Ensures that all planned inspection and test operations were carried out with the result "pass".

Report Generator

  • Comprehensive statistical reports.
  • Drill down capabilities for quick analysis of abnormalities to help provide quality improvements.
